基于商值法的镧水生态风险评价方法研究及应用
Ecological Risk Assessment of Lanthanum in Water Based on Risk Quotient
-
摘要: 随着我国稀土资源开发和利用，稀土元素对水生生态环境的影响及其生态风险越来越受关注。本文以稀土镧的通用敏感生物急性半致死/效应浓度(half lethal/effect concentration,L (E) C50)和慢性无观察效应浓度(no observed effect concentration,NOEC)数据，分别采用评价因子法和物种敏感度分布法(species sensitivity distribution,SSD)推导计算了镧的预测无效应浓度(predicted no effect concentration,PNEC)，比较不同数据类型和计算方法的结果差异及不确定性，并以四川安宁河为例进行了水生态风险表征。采用评价因子法推导的急性和慢性PNEC分别为1.180 μg·L-1和4.000 μg·L-1。由急性数据拟合SSD曲线推导的PNEC为42.770 μg·L-1，通过急慢性比(acute to chronic ratio,ACR)转换的PNEC为2.032 μg·L-1。在慢性数据缺乏的情况下，ACR-SSD是相对可行的方法。安宁河镧的水生态风险评价结果表明，所有调查断面均处于中等以上生态风险，其稀土污染问题应引起重视。Abstract: Rare earth elements (REE) are increasingly being used in agriculture and high technology materials worldwide. Massive exploitation and use of REEs have inevitably led to their large-scale releasing into aquatic ecosystems, resulting in various environmental issues. In this study, we collected the acute toxicity data (half lethal/effect concentration, L(E)C50) and chronic toxicity data (no observed effect concentration, NOEC) of lanthanum to calculate predicted no effect concentration (PNEC). The results were compared between the assessment factor method and species sensitive distribution method (SSD). The uncertainties of the data and methods were discussed. The Anning River in Sichuan Province was selected as a case study. The ecological risks of river water were characterized by risk quotient. The results showed that the acute and chronic PNEC derived by the assessment factor method were 1.180 μg·L-1 and 4.000 μg·L-1, respectively. The PNEC derived by SSD method based on the acute toxicity data of L(E)C50 was 42.770 μg·L-1, while it was 2.032 μg·L-1 calculating with an acute to chronic ratio (ACR). The ACR-SSD method was relatively feasible when the chronic toxicology data size is far from the requirements for SSD construction. Assessment of lanthanum toxicity in Anning River found that risk quotient (RQ) values were significantly higher than 0.1, indicating that the adverse effects of lanthanum should be not ignored.
-
Key words:
- lanthanum /
- acute and chronic toxicity /
- ecological risk /
- PNEC
-
-
Gwenzi W, Mangori L, Danha C, et al. Sources, behaviour, and environmental and human health risks of high-technology rare earth elements as emerging contaminants[J]. The Science of the Total Environment, 2018, 636:299-313 Gonzalez V, Vignati D A, Leyval C, et al. Environmental fate and ecotoxicity of lanthanides:Are they a uniform group beyond chemistry?[J]. Environment International, 2014, 71:148-157 Herrmann H, Nolde J, Berger S, et al. Aquatic ecotoxicity of lanthanum:A review and an attempt to derive water and sediment quality criteria[J]. Ecotoxicology and Environmental Safety, 2016, 124:213-238 Malhotra N, Hsu H S, Liang S T, et al. An updated review of toxicity effect of the rare earth elements (REEs) on aquatic organisms[J]. Animals, 2020, 10(9):1663 金姝兰,黄益宗,王斐,等.江西典型钨矿开采对周边环境稀土元素含量的影响[J].环境科学学报, 2016, 36(4):1328-1335 Jin S L, Huang Y Z, Wang F, et al. Rare earth elements content in farmland soils, crops and river near a typical Tungsten Ore in Jiangxi Province[J]. Acta Scientiae Circumstantiae, 2016, 36(4):1328-1335(in Chinese)
付小方,侯立玮,袁蔺平,等.四川冕宁南河马厂村稀土尾矿调查评价及开发利用建议[J].中国稀土学报, 2017, 35(2):272-282 Fu X F, Hou L W, Yuan L P, et al. Proposals on development and application, the investigation and assessment of Nanhe-Machangcun REE tailings mining of Sichuan[J]. Journal of the Chinese Society of Rare Earths, 2017, 35(2):272-282(in Chinese)
张家玮,齐观景,赵昊铎,等.基于物种敏感性分布评价长三角地区地表水壬基酚生态风险[J].生态毒理学报, 2020, 15(3):134-148 Zhang J W, Qi G J, Zhao H D, et al. Ecological risk assessment of nonylphenol in surface waters of the Yangtze River Delta based on species sensitivity distribution model[J]. Asian Journal of Ecotoxicology, 2020, 15(3):134-148(in Chinese)
Gu Y G, Gao Y P, Huang H H, et al. First attempt to assess ecotoxicological risk of fifteen rare earth elements and their mixtures in sediments with diffusive gradients in thin films[J]. Water Research, 2020, 185:116254 林荣华,姜辉,王猛,等.物种敏感度分布(SSD)方法在农药环境风险评估中的应用[J].生态毒理学报, 2017, 12(4):110-118 Lin R H, Jiang H, Wang M, et al. Application of species sensitivity distribution (SSD) to the environmental risk assessment of pesticides[J]. Asian Journal of Ecotoxicology, 2017, 12(4):110-118(in Chinese)
European Chemicals Agency. Chapter R.10:Characterisation of dose[concentration]-response for environment. Guidance on information requirements and chemical safety[R]. Helsinki, Finland:European Chemicals Agency, 2008 Chen H B, Chen Z B, Chen Z Q, et al. Calculation of toxicity coefficient of potential ecological risk assessment of rare earth elements[J]. Bulletin of Environmental Contamination and Toxicology, 2020, 104(5):582-587 Xu F L, Li Y L, Wang Y, et al. Key issues for the development and application of the species sensitivity distribution (SSD) model for ecological risk assessment[J]. Ecological Indicators, 2015, 54:227-237 European Chemicals Agency. Chapter R.4:Evaluation of available information. Guidance on information requirements and chemical safety assessment[R]. Helsinki, Finland:European Chemicals Agency, 2011 Klimisch H J, Andreae M, Tillmann U. A systematic approach for evaluating the quality of experimental toxicological and ecotoxicological data[J]. Regulatory Toxicology and Pharmacology, 1997, 25(1):1-5 Oosterhout F, Lürling M. The effect of phosphorus binding clay (Phoslock®) in mitigating cyanobacterial nuisance:A laboratory study on the effects on water quality variables and plankton[J]. Hydrobiologia, 2013, 710(1):265-277 Lürling M, Tolman Y. Effects of lanthanum and lanthanum-modified clay on growth, survival and reproduction of Daphnia magna [J]. Water Research, 2010, 44(1):309-319 Barry M J, Meehan B J. The acute and chronic toxicity of lanthanum to Daphnia carinata [J]. Chemosphere, 2000, 41(10):1669-1674 Bergsten-Torralba L R, Magalhães D P, Giese E C, et al. Toxicity of three rare earth elements, and their combinations to algae, microcrustaceans, and fungi[J]. Ecotoxicology and Environmental Safety, 2020, 201:110795 Borgmann U, Couillard Y, Doyle P, et al. Toxicity of sixty-three metals and metalloids to Hyalella azteca at two levels of water hardness[J]. Environmental Toxicology and Chemistry, 2005, 24(3):641-652 Blinova I, Lukjanova A, Muna M, et al. Evaluation of the potential hazard of lanthanides to freshwater microcrustaceans[J]. The Science of the Total Environment, 2018, 642:1100-1107 Dubé M, Auclair J, Hanana H, et al. Gene expression changes and toxicity of selected rare earth elements in rainbow trout juveniles[J]. Comparative Biochemistry and Physiology Toxicology&Pharmacology, 2019, 223:88-95 Xu Q S, Fu Y Y, Min H L, et al. Laboratory assessment of uptake and toxicity of lanthanum (La) in the leaves of Hydrocharis dubia (Bl.) Backer[J]. Environmental Science and Pollution Research International, 2012, 19(9):3950-3958 Ahlers J, Riedhammer C, Vogliano M, et al. Acute to chronic ratios in aquatic toxicity-Variation across trophic levels and relationship with chemical structure[J]. Environmental Toxicology and Chemistry, 2006, 25(11):2937-2945 United States Environmental Protection Agency (US EPA). Guidelines for deriving numerical national water quality criteria for the protection of aquatic organisms and their uses[R]. Washington DC:US EPA, 1985 陈锦灿,方超,郑榕辉,等.应用物种敏感性分布评估微(纳米)塑料对水生生物的生态风险[J].生态毒理学报, 2020, 15(1):242-255 Chen J C, Fang C, Zheng R H, et al. Assessing ecological risks of micro (nano) plastics to aquatic organisms using species sensitivity distributions[J]. Asian Journal of Ecotoxicology, 2020, 15(1):242-255(in Chinese)
冯永亮.物种敏感度分布的模型选择和最小样本量研究[J].安全与环境学报, 2020, 20(5):1990-2000 Feng Y L. Investigation of model choice and minimum sampling size for species sensitivity distribution[J]. Journal of Safety and Environment, 2020, 20(5):1990-2000(in Chinese)
刘帆,孔昊玥,刘红玲.基于权重敏感度分布研究太湖有机磷农药单一和复合风险[J].生态毒理学报, 2020, 15(2):130-140 Liu F, Kong H Y, Liu H L. Study on risk of organophosphate pesticides mixture in Tai Lake based on weight species sensitivity distribution[J]. Asian Journal of Ecotoxicology, 2020, 15(2):130-140(in Chinese)
王立军,章申,张朝生,等.长江中下游稀土元素的水环境地球化学特征[J].环境科学学报, 1995, 15(1):57-65 Wang L J, Zhang S, Zhang C S, et al. Aquatic environmental geochemistry characteristics of rare earth elements in the middle-lower reaches of Changjiang (Yangtzi) River[J]. Acta Scientiae Circumstantiae, 1995, 15(1):57-65(in Chinese)
茹辉军,张燕,李云峰,等.雅砻江支流安宁河鱼类群落组成及资源现状[J].水生态学杂志, 2016, 37(5):68-74 Ru H J, Zhang Y, Li Y F, et al. Community composition and status of fish resources in Anning River[J]. Journal of Hydroecology, 2016, 37(5):68-74(in Chinese)
张志霞,王斌,袁宏林,等.运用物种敏感度分布法推导磺胺类药物的水质基准[J].环境科学与技术, 2016, 39(12):184-188 Zhang Z X, Wang B, Yuan H L, et al. Deriving aquatic water quality criteria for sulfonamides by species sensitivity distributions[J]. Environmental Science&Technology, 2016, 39(12):184-188(in Chinese)
-
