绍兴茶园小流域的3种农药生态风险评价
Ecological Risk Assessment of Three Pesticides in Small Watershed of Shaoxing Tea Plantation
-
摘要: 虫螨腈、联苯菊酯和溴氰菊酯是茶叶生产中较为常见的3种杀虫剂，但其对茶园小流域内生态环境影响的相关研究较少。为评价其生态风险，选取我国浙江绍兴茶园小流域内主要溪流及湖库采集水体样品，采用气相色谱-质谱法对样品中3种农药进行残留检测；基于美国生态毒理数据库(ECOTOX)收集了3种农药对我国常见水生生物的毒性数据，利用BITSSD软件平台构建了物种敏感度分布(species sensitivity distribution,SSD)曲线，结合研究区实测数据开展3种农药对绍兴茶园小流域的生态风险评价研究。结果表明：(1)无脊椎动物和节肢动物对3种农药的敏感度高于鱼类，营养级越高其敏感度越低；(2)根据SSD模拟结果，为保护该流域95%的物种，联苯菊酯和溴氰菊酯浓度需<0.001 μg·L-1，虫螨腈为0.4 μg·L-1；(3)农药喷施后，虫螨腈、溴氰菊酯和联苯菊酯在茶园溪流中的残留浓度最高分别影响22%、50%和66%的物种，联苯菊酯是生态风险的主要贡献者，但在喷施1个月后，茶园流域水溪及河湖水环境中的农药残留基本均未检出。这说明3种农药施用对茶园小流域物种的影响较小，所带来的生态风险尚在可控范围之内。Abstract: Chlorfenapyr, bifenthrin and deltamethrin are three insecticides commonly used in tea plantation, but studies on their effects on the eco-environment in small watershed of tea plantation are scarce. In order to evaluate the ecological risks, water samples were collected from the main streams and lakes in the watershed of tea plantation of Shaoxing, Zhejiang Province, China. The residues of three pesticides in the samples were measured by Gas Chromatography-Triple Quadrupole Mass Spectrometer. The toxicity data of three pesticides to common aquatic organisms in China were collected from the ECOTOX. The BITSSD software platform was used to construct species sensitivity distribution (SSD) curve. Using the residual data measured in the study area, the ecological risk assessment of the three pesticides on the small watershed of Shaoxing tea plantation was carried out. The results showed that:(1) The sensitivity of invertebrates and arthropods to the three pesticides was higher than that of fish, and the lower the trophic level, the higher the sensitivity; (2) According to the results of SSD simulation, the thresholds of bifenthrin and deltamethrin should be less than 0.001 μg·L-1 and 0.4 μg·L-1 for chlorfenapyr in order to protect 95% of the species in the watershed; (3) After pesticide spraying, the residue concentrations of chlorfenapyr, deltamethrin and bifenthrin in the streams of tea garden affected 22%, 50% and 66% of the species, respectively. Bifenthrin was the main contributor to ecological risk. However, one month after pesticide spraying, the pesticide residues in water samples of the river and lake around the tea plantation were not detected, indicating that the pesticide residues were quite low which could hardly produce eminent impact to the local biota of the watersheds, thus the ecological risks brought by the three pesticide residues around the tea plantation are generally in control.
-
Key words:
- pesticides /
- tea plantation /
- small watershed /
- the species sensitivity distribution /
- ecological risk
-
-
赵李娜,赖子尼,张威振,等.珠江河网水产品中菊酯类农药残留调查及健康风险评价[J].生态毒理学报, 2014, 9(3):437-444 Zhao L N, Lai Z N, Zhang W Z, et al. Residual levels and health risk assessment of pyrethroid pesticides in aquatic products of the Pearl River Delta[J]. Asian Journal of Ecotoxicology, 2014, 9(3):437-444(in Chinese)
赵玲,滕应,骆永明.中国农田土壤农药污染现状和防控对策[J].土壤, 2017, 49(3):417-427 Zhao L, Teng Y, Luo Y M. Present pollution status and control strategy of pesticides in agricultural soils in China:A review[J]. Soils, 2017, 49(3):417-427(in Chinese)
马畅,刘新刚,吴小虎,等.农田土壤中的农药残留对农产品安全的影响研究进展[J].植物保护, 2020, 46(2):6-11 Ma C, Liu X G, Wu X H, et al. Research progress in the impact of pesticide residues in farmland soil on agricultural product safety[J]. Plant Protection, 2020, 46(2):6-11(in Chinese)
魏启文,陶传江,宋稳成,等.农药风险评估及其现状与对策研究[J].农产品质量与安全, 2010(2):38-42 雷昌文,曹莹,周腾耀,等.太湖水体中5种有机磷农药混合物生态风险评价[J].生态毒理学报, 2013, 8(6):937-944 Lei C W, Cao Y, Zhou T Y, et al. Ecological risk assessment of five organophosphorus pesticides mixture in Taihu Lake[J]. Asian Journal of Ecotoxicology, 2013, 8(6):937-944(in Chinese)
Maltby L, Blake N, Brock T C, et al. Insecticide species sensitivity distributions:Importance of test species selection and relevance to aquatic ecosystems[J]. Environmental Toxicology and Chemistry, 2005, 24(2):379-388 周怡彤,李清雪,王斌,等.太湖流域西北部地表水中农药的污染特征及生态风险评价[J].生态毒理学报, 2020, 15(3):171-183 Zhou Y T, Li Q X, Wang B, et al. Distribution and ecotoxicological risk assessment of pesticides in surface water of the northwest of Taihu Lake Basin[J]. Asian Journal of Ecotoxicology, 2020, 15(3):171-183(in Chinese)
Fox D R, Dam R A V, Fisher R, et al. Recent developments in species sensitivity distribution modeling[J]. Environmental Toxicology and Chemistry, 2021, 40(2):293-308 van Wijngaarden R P A, Arts G H P, Belgers J D M, et al. The species sensitivity distribution approach compared to a microcosm study:A case study with the fungicide fluazinam[J]. Ecotoxicology and Environmental Safety, 2010, 73(2):109-122 Sorgog K, Kamo M. Quantifying the precision of ecological risk:Conventional assessment factor method vs. species sensitivity distribution method[J]. Ecotoxicology and Environmental Safety, 2019, 183:109494 赵之德,李海涛,梁涛.联苯菊酯等3种杀虫剂在茶园茶叶、土壤及降雨径流中的残留[J].中国生态农业学报(中英文), 2019, 27(8 ):1265-1274Zhao Z D, Li H T, Liang T. Residues of three insecticides in tea leaves, soil and rainwater runoff[J]. Chinese Journal of Eco-Agriculture, 2019, 27(8):1265-1274(in Chinese)
Yang J, Luo F J, Zhou L, et al. Residue reduction and risk evaluation of chlorfenapyr residue in tea planting, tea processing, and tea brewing[J]. Science of the Total Environment, 2020, 738:139613 赵晨,彭书传,陈天虎,等.巢湖流域和太湖流域沉积物中苄氯菊酯和高效氰戊菊酯的生态风险评价[J].环境科学学报, 2016, 36(3):1080-1091 Zhao C, Peng S C, Chen T H, et al. Ecological risk assessment of sediment-associated permethrin and esfenvalerate in Chaohu Lake and Taihu Lake watersheds[J]. Acta Scientiae Circumstantiae, 2016, 36(3):1080-1091(in Chinese)
杨浩瑜,刘惠见,张乃明,等.化肥减施处理对茶园土壤养分及茶叶品质的影响[J].南方农业学报, 2020, 51(4):887-896 Yang H Y, Liu H J, Zhang N M, et al. Effects of different fertilization application reduction methods on tea garden soil nutrient and tea quality[J]. Journal of Southern Agriculture, 2020, 51(4):887-896(in Chinese)
谢邵文,杨芬,冯含笑,等.中国化肥农药施用总体特征及减施效果分析[J].环境污染与防治, 2019, 41(4):490-495 Xie S W, Yang F, Feng H X, et al. General characteristics of the chemical fertilizers and pesticides use and the analysis of use reduction effect in China[J]. Environmental Pollution&Control, 2019, 41(4):490-495(in Chinese)
吴爱明.我国水质基准数据整编技术方法初步研究——以美国生态毒性数据整编为例[D].昆明:昆明理工大学, 2017:35-38Wu A M. Preliminary research on technical method for compilation for water quality criteria in China-Using the compilation for US ecotoxicology data as a case[D]. Kunming:Kunming University of Science and Technology, 2017:35 -38(in Chinese)
吴爱明,赵晓丽,冯宇,等.美国生态毒理数据库(ECOTOX)对中国数据库构建的启示[J].环境科学研究, 2017, 30(4):636-644 Wu A M, Zhao X L, Feng Y, et al. The enlightenment of the ecotoxicology knowledgebase (ECOTOX) for its establishment in China[J]. Research of Environmental Sciences, 2017, 30(4):636-644(in Chinese)
He W, Kong X Z, Qin N, et al. Combining species sensitivity distribution (SSD) model and thermodynamic index (exergy) for system-level ecological risk assessment of contaminates in aquatic ecosystems[J]. Environment International, 2019, 133(Pt B):105275 Pérez D J, Iturburu F G, Calderon G, et al. Ecological risk assessment of current-use pesticides and biocides in soils, sediments and surface water of a mixed land-use basin of the Pampas region, Argentina[J]. Chemosphere, 2021, 263:128061 Guarda P M, Pontes A M S, Domiciano R S, et al. Assessment of ecological risk and environmental behavior of pesticides in environmental compartments of the Formoso River in Tocantins, Brazil[J]. Archives of Environmental Contamination and Toxicology, 2020, 79(4):524-536 林荣华,姜辉,王猛,等.物种敏感度分布(SSD)方法在农药环境风险评估中的应用[J].生态毒理学报, 2017, 12(4):110-118 Lin R H, Jiang H, Wang M, et al. Application of species sensitivity distribution (SSD) to the environmental risk assessment of pesticides[J]. Asian Journal of Ecotoxicology, 2017, 12(4):110-118(in Chinese)
张晓惠,袁雪竹,陈红,等.基于SSD法的持久性污染物水生态风险阈值研究[J].生态科学, 2016, 35(3):85-91 Zhang X H, Yuan X Z, Chen H, et al. The aquatic ecological risk thresholds of persistent organic pollutants based on species sensitivity distribution[J]. Ecological Science, 2016, 35(3):85-91(in Chinese)
王婷,张红,史雅娟,等.我国硒淡水水生生物水质基准值推导[J].环境科学学报, 2020, 40(4):1278-1285 Wang T, Zhang H, Shi Y J, et al. Derivation of freshwater quality criteria of selenium for protection of aquatic organisms in China[J]. Acta Scientiae Circumstantiae, 2020, 40(4):1278-1285(in Chinese)
李会仙,张瑞卿,吴丰昌,等.中美淡水生物区系中汞物种敏感度分布比较[J].环境科学学报, 2012, 32(5):1183-1191 Li H X, Zhang R Q, Wu F C, et al. Comparison of mercury species sensitivity distributions of freshwater biota in China and the United States[J]. Acta Scientiae Circumstantiae, 2012, 32(5):1183-1191(in Chinese)
苏海磊,吴丰昌,李会仙,等.太湖生物区系研究及与北美五大湖的比较[J].环境科学研究, 2011, 24(12):1346-1354 Su H L, Wu F C, Li H X, et al. Aquatic biota of Taihu Lake and comparison with those of the North American great lakes[J]. Research of Environmental Sciences, 2011, 24(12):1346-1354(in Chinese)
中华人民共和国环境保护部.淡水水生生物水质基准制定技术指南:HJ 831-2017[S].北京:中国环境出版社, 2017 刘鸿亮.湖泊富营养化调查规范[M].北京:中国环境科学出版社, 1987:138-152 Thunnissen N W, Lautz L S, van Schaik T W G, et al. Ecological risks of imidacloprid to aquatic species in the Netherlands:Measured and estimated concentrations compared to species sensitivity distributions[J]. Chemosphere, 2020, 254:126604 肖鹏飞,林晓雅,刘毅华,等.基于物种敏感性分布法的毒死蜱对稻田生态系统生态风险评价[J].生态毒理学报, 2017, 12(3):398-407 Xiao P F, Lin X Y, Liu Y H, et al. Application of species sensitivity distribution in aquatic ecological risk assessment of chlopyrifos for paddy ecosystem[J]. Asian Journal of Ecotoxicology, 2017, 12(3):398-407(in Chinese)
江阳,王艳,魏红,等.高效液相色谱-串联质谱法同时测定饮用水中的13种农药残留[J].中国卫生检验杂志, 2016, 26(2):184-188 Jiang Y, Wang Y, Wei H, et al. Determination of thirteen pesticides in drinking water by HPLC-MS/MS[J]. Chinese Journal of Health Laboratory Technology, 2016, 26(2):184-188(in Chinese)
刘亚莉,谢玉为,张效伟,等.应用物种敏感性分布评价敌敌畏对淡水生物的生态风险[J].生态毒理学报, 2016, 11(2):531-538 Liu Y L, Xie Y W, Zhang X W, et al. Assessing ecological risks of dichlorvos to freshwater organisms by species sensitivity distribution[J]. Asian Journal of Ecotoxicology, 2016, 11(2):531-538(in Chinese)
Lee M S, Lee J H, An Y J, et al. Development of water quality criteria for arsenic to protect aquatic life based on species sensitivity distribution[J]. Ecotoxicology and Environmental Safety, 2020, 189:109933 陈波宇,郑斯瑞,牛希成,等.水生生物对三唑磷的物种敏感度分布研究[J].环境科学, 2011, 32(4):1101-1107 Chen B Y, Zheng S R, Niu X C, et al. Species sensitive distribution for aquatic biota exposed to triazophos[J]. Environmental Science, 2011, 32(4):1101-1107(in Chinese)
张家玮,齐观景,赵昊铎,等.基于物种敏感性分布评价长三角地区地表水壬基酚生态风险[J].生态毒理学报, 2020, 15(3):134-148 Zhang J W, Qi G J, Zhao H D, et al. Ecological risk assessment of nonylphenol in surface waters of the Yangtze River Delta based on species sensitivity distribution model[J]. Asian Journal of Ecotoxicology, 2020, 15(3):134-148(in Chinese)
王铜,孙傅,曾思育,等.北京市污水处理厂出水中雌二醇的概率生态风险评价[J].生态毒理学报, 2015, 10(1):271-280 Wang T, Sun F, Zeng S Y, et al. Probabilistic ecological risk assessment of estradiol in the effluents of wastewater treatment plants in Beijing[J]. Asian Journal of Ecotoxicology, 2015, 10(1):271-280(in Chinese)
李晓阳,孙傅,曾思育,等.某湿地生态保护区水体中铜的生态风险评价及管理限值研究[J].生态毒理学报, 2014, 9(4):647-656 Li X Y, Sun F, Zeng S Y, et al. Ecological risk assessment and derivation of a guideline value for copper in the water of a wetland reserve[J]. Asian Journal of Ecotoxicology, 2014, 9(4):647-656(in Chinese)
Dowse R, Tang D D, Palmer C G, et al. Risk assessment using the species sensitivity distribution method:Data quality versus data quantity[J]. Environmental Toxicology and Chemistry, 2013, 32(6):1360-1369 -
