实时荧光定量PCR技术在太湖蓝藻监测和评估中的应用
Application of Quantitative PCR Technology in Biomonitoring and Assessment of Harmful Cyanobacteria in Lake Tai
-
摘要: 我国东部地区的湖泊深受蓝藻水华的影响，监测可产生毒素的藻种类及其浓度对于水质安全预警与管理有重要意义。然而传统形态学方法无法鉴别藻类产生毒素及嗅味物质的潜在趋势。为综合评估湖泊及其水源水体的藻类有毒代谢物发生风险，采用实时定量聚合酶链式反应（quantitative real-time polymerase chain reaction，qPCR）方法对太湖产毒微囊藻基因、产毒柱孢藻基因和产2-甲基异莰醇基因进行监测，同时采用盘式酶联免疫法（enzyme-linked immuno-sorbent assay，ELISA）以及气相色谱-质谱法分析微囊藻毒素、柱孢藻毒素和2-甲基异莰醇浓度，并进行相关性分析。结果表明，太湖水体各项蓝藻产毒基因水平与相关藻毒素浓度具有良好相关性。由蓝藻产毒基因/藻种基因丰度的比值可知，高丰度的微囊藻菌株不具有产藻毒素的潜力，而绝大多数柱孢藻都含有产毒素的基因，表明采用产毒基因的拷贝数预测藻种的产毒能力更准确。不同类型的产毒藻基因在太湖具有显著的时空分布差异，产毒微囊藻基因在9月达到浓度峰值，在太湖西部浓度更高，而产毒柱孢藻和产2-甲基异莰醇基因则在7-8月达到峰值，在中部和东部维持较高浓度。太湖的饮用水源地2-甲基异莰醇风险显著高于微囊藻毒素和柱孢藻毒素。因此，分子生物监测和评估可为蓝藻预警与管理提供重要支撑。Abstract: The lakes in eastern China have been heavily affected by cyanobacterial blooms. Monitoring the toxic algae species and concentrations of their corresponding toxic metabolites are pre-requirement for water quality management. However, traditional morphological methods are limited in the identification of the potential trend of algae producing toxins and odorants. To comprehensively assess the risk of toxic metabolites of algae in Lake Tai, the real-time quantitative polymerase chain reaction (qPCR) assays were developed for quantifying potentially toxigenic Microcystis, cylindrospermopsin-producing and 2-methylisoborneol (2-MIB)-synthesis cyanobacteria. Furthermore, the concentrations of corresponding toxins were measured by enzyme-linked immuno-sorbent assay and gas chromatography-mass spectrometry method. The results showed statistically significant correlations between the levels of toxigenic genes and the concentrations of corresponding toxins in Lake Tai. The low ratio of the gene copies from toxic Microcystis to that from total Microcystis showed that the high abundance of Microcystis strains weren't potential to produce toxins. However, most of Cylindrospermopsis cells were potentially toxigenic as showed by the data. It is indicated that the copy numbers of toxin producing genes are accurate enough to diagnose the presence of harmful cyanobacteria and the potential presence of cyanotoxins in Lake Tai. Significant differences in the temporal and spatial distribution of toxigenic genes were observed for different types of toxic algae. The gene copies of toxigenic Microcystis reached the peak in the west of Lake Tai and showed higher abundance in September, while the copies of cylindrospermopsin-producing gene and 2-MIB synthesis gene of cyanobacteria remained high in the middle and east of Lake Tai and reached peaks in July and August. The risk of 2-MIB in drinking water sources of Lake Tai was significantly higher than that of microcystin and cylindrospermopsin. In conclusion, molecular biological monitoring and assessment can provide important powerful tools for cyanobacteria early warning and management.
-
Key words:
- cyanotoxin /
- odor compound /
- Lake Tai /
- Microcystis /
- cylindrospermopsin /
- qPCR
-
-
中华人民共和国环境保护部. 湖库富营养化防治技术政策:环发[2004] 59号[Z]. 北京:中华人民共和国环境保护部, 2004 Carmichael W W. Cyanobacteria secondary metabolites-The cyanotoxins[J]. The Journal of Applied Bacteriology, 1992, 72(6):445-459 Otsuka S, Suda S, Li R H, et al. Phylogenetic relationships between toxic and non-toxic strains of the genus Microcystis based on 16S to 23S internal transcribed spacer sequence[J]. FEMS Microbiology Letters, 1999, 172(1):15-21 Fastner J, Erhard M, von Döhren H. Determination of oligopeptide diversity within a natural population of Microcystis spp. (Cyanobacteria) by typing single colonies by matrix-assisted laser desorption ionization-time of flight mass spectrometry[J]. Applied & Environmental Microbiology, 2001, 67(11):5069-5076 Alster A, Kaplan-Levy R N, Sukenik A, et al. Morphology and phylogeny of a non-toxic invasive Cylindrospermopsis raciborskii from a Mediterranean Lake[J]. Hydrobiologia, 2010, 639(1):115-128 Rouhiainen L, Sivonen K, Buikema W J, et al. Characterization of toxin-producing cyanobacteria by using an oligonucleotide probe containing a tandemly repeated heptamer[J]. Journal of Bacteriology, 1995, 177(20):6021-6026 Chiu Y T, Chen Y H, Wang T S, et al. A qPCR-based tool to diagnose the presence of harmful cyanobacteria and cyanotoxins in drinking water sources[J].International Journal of Environmental Research and Public Health, 2017, 14(5):547 Tsao H W, Michinaka A, Yen H K, et al. Monitoring of geosmin producing Anabaena circinalis using quantitative PCR[J]. Water Research, 2014, 49:416-425 Pearson L A, Neilan B A. The molecular genetics of cyanobacterial toxicity as a basis for monitoring water quality and public health risk[J]. Current Opinion in Biotechnology, 2008, 19(3):281-288 Michinaka A, Yen H K, Chiu Y T, et al. Rapid on-site multiplex assays for total and toxigenic Microcystis using real-time PCR with microwave cell disruption[J]. Water Science and Technology, 2012, 66(6):1247-1252 Lei L, Lei M, Lu Y, et al. Development of real-time PCR for quantification of Cylindrospermopsis raciborskii cells and potential cylindrospermopsin-producing genotypes in subtropical reservoirs of southern China[J]. Journal of Applied Phycology, 2019, 31:3749-3758 Ouahid Y, del Campo F F. Typing of toxinogenic Microcystis from environmental samples by multiplex PCR[J]. Applied Microbiology and Biotechnology, 2009, 85(2):405-412 Sevilla E, Martin-Luna B, Vela L, et al. Microcystin-LR synthesis as response to nitrogen:Transcriptional analysis of the mcyD gene in Microcystis aeruginosa PCC7806[J]. Ecotoxicology, 2010, 19(7):1167-1173 Ngwa F F, Madramootoo C A, Jabaji S. Development and application of a multiplex qPCR technique to detect multiple microcystin-producing cyanobacterial genera in a Canadian freshwater lake[J]. Journal of Applied Phycology, 2014, 26(4):1675-1687 Ouahid Y, Pérez-Silva G, del Campo F F. Identification of potentially toxic environmental Microcystis by individual and multiple PCR amplification of specific microcystin synthetase gene regions[J]. Environmental Toxicology, 2005, 20(3):235-242 刘洋, 胡佩茹, 马思三, 等. 实时荧光定量PCR方法检测南太湖入湖口产毒微囊藻[J]. 湖泊科学, 2016, 28(2):246-252 Liu Y, Hu P R, Ma S S, et al. Detection of microcystin-producing Microcystis cells at the entrance of rivers to southern Lake Taihu by real-time fluorescence quantitative PCR[J]. Journal of Lake Sciences, 2016, 28(2):246-252(in Chinese)
Rasmussen J P, Giglio S, Monis P T, et al. Development and field testing of a real-time PCR assay for cylindrospermopsin-producing cyanobacteria[J]. Journal of Applied Microbiology, 2008, 104(5):1503-1515 Marbun Y R, Yen H K, Lin T F, et al. Rapid on-site monitoring of cylindrospermopsin-producers in reservoirs using quantitative PCR[J]. Sustainable Environment Research, 2012, 22(3):143-151 Baker L, Sendall B C, Gasser R B, et al. Rapid, multiplex-tandem PCR assay for automated detection and differentiation of toxigenic cyanobacterial blooms[J]. Molecular and Cellular Probes, 2013, 27(5-6):208-214 Te S H, Chen E Y, Gin K Y H. Comparison of quantitative PCR and droplet digital PCR multiplex assays for two genera of bloom-forming cyanobacteria, Cylindrospermopsis and Microcystis[J]. Applied and Environmental Microbiology, 2015, 81(15):5203-5211 Wang Z J, Song G F, Shao J H, et al. Establishment and field applications of real-time PCR methods for the quantification of potential MIB-producing cyanobacteria in aquatic systems[J]. Journal of Applied Phycology, 2016, 28(1):325-333 Chiu Y T, Yen H K, Lin T F. An alternative method to quantify 2-MIB producing cyanobacteria in drinking water reservoirs:Method development and field applications[J]. Environmental Research, 2016, 151:618-627 Fischer W J, Garthwaite I, Miles C O, et al. Congener-independent immunoassay for microcystins and nodularins[J]. Environmental Science & Technology, 2001, 35(24):4849-4856 Lin T F, Liu C L, Yang F C, et al. Effect of residual chlorine on the analysis of geosmin, 2-MIB and MTBE in drinking water using the SPME technique[J]. Water Research, 2003, 37(1):21-26 Montgomery D C, Peck E A, Vining G G. Introduction to Linear Regression Analysis[M]. Wiley, 1982:9-37 World Health Organization (WHO). International Programme on Chemical Safety. Guidelines for drinking-water quality:Volume 2:Health criteria and other supporting information[R]. Geneva:WHO, 1996 Humpage A R, Falconer I R. Oral toxicity of the cyanobacterial toxin cylindrospermopsin in male Swiss albino mice:Determination of no observed adverse effect level for deriving a drinking water guideline value[J]. Environmental Toxicology, 2003, 18(2):94-103 徐晓庆, 苏命, 朱宜平, 等. 基于荧光定量PCR技术构建水源地典型致嗅物质2-甲基异莰醇的评估方法及其应用[J]. 环境工程学报, 2020, 14(11):3208-3215 Xu X Q, Su M, Zhu Y P, et al. Evaluation of typical odorant 2-methylisoborneol based on real time qPCR in source water and its application[J]. Chinese Journal of Environmental Engineering, 2020, 14(11):3208-3215(in Chinese)
-
