砂柱对济南城市屋面雨水径流净化效果的试验
Purification of roof rainwater in Jinan by sand fileration column
-
摘要: 针对屋面雨水回灌裂隙岩溶含水层要求快速量大和水质要求高的特点,设计了相适宜的砂滤柱.采用室内砂滤试验研究了济南市屋面雨水径流回灌裂隙岩溶含水层之前的雨水净化效果.结果表明,砂柱对屋面雨水径流污染物有明显的去除效果,浊度的平均去除率达到87%,悬浮物的平均去除率达到70%以上,对色度、挥发酚、Pb和Zn也有一定的去除效果,对NH3-N、NO2-N的去除效果较差.浊度、色度和悬浮物等大部分污染物的去除主要集中在上层完成,因此,砂柱的上层需要定期更换.
-
关键词:
- 屋面雨水径流 /
- 砂滤柱 /
- 裂隙岩溶含水层补给管理
Abstract: To fulfill the requirements of high speed, large volume and high water quality for roof rainwater recharging fracture-karst aquifer, sand filtration column was designed. Sand filtration test in the laboratory was conducted to investigate the effect of roof rainwater purification in Jinan as pretreatment for fracture-karst aquifer recharge. The results show that the sand filtration column is effective in removing pollutants in roof rainwater. The average removal rate of turbidity reached 87%, and the average removal rate of suspended solids was above 70%; The sand column was also effective in removing color, volatile phenol, lead and zinc to a certain degree. However, it had a poor effect in removing ammonia nitrogen and nitrite nitrogen. In addition, the removal of most pollutants such as turbidity, color and suspended solids mainly occurred in the upper layer, which needs to be replaced regularly. -
-
[1] 冯绍元, 侯立柱, 丁跃元, 等. 多层渗滤介质系统去除城市雨水径流有机污染物[J]. 环境科学学报, 2008, 28(6): 1123-1130 [2] 纪桂霞, 王平香, 邱卫国. 上海市屋面雨水水质监测与处理利用方法研究[J]. 上海理工大学学报, 2008, 28(6): 594-598 [3] 张国臣, 陈鸿汉, 何江涛. 人工快速渗滤系统在城市雨水资源化中的应用[J]. 工程技术, 2008, 390: 76-78 [4] 田景宏, 黄柄彬. 砂滤人工湿地处理污染河水运行研究[J]. 水处理技术, 2008, 34(8): 49-51 [5] Eighmy Taylor, Collins M Robin, Spanos S K, et al. Microbial Populations, activities and carbon metabolism in slow sand filters[J]. Water Research, 1992, 26(10): 1319-1328 [6] Adin A. Slow granular filtration for water reuse[J]. Water Science and Technology: Water Supply, 2003, 42: 123-130 [7] 雷鹏举, 曲久辉, 杨日光. 微絮凝直接纤维过滤处理低浊水试验研究[J]. 环境化学, 1999, 18(6): 561-565 [8] 车武, 汪慧珍, 任超. 北京城区屋面雨水污染及利用研究[J]. 中国给水排水, 2001, 17(6):57-61 [9] [10] [11] Hatt B E, Fletch T D, Deletic A. Treat performance of gravel filter media: Implications for design and application of stormwater infiltration systems[J]. Water Research, 2007,41: 2513-2524 [12] Hatt B E, Siriwardene N, Deletic A, et al. Filter media for stormwater treatment and recycling: the influence of hydraulic properties of flow on pollutant removal//10th International Conference on Urban Drainage. Copenhagen, Denmark, 2005: 1-6 [13] Siriwardene N R, Deletic A, Fletcher T D. Clogging of stormwater gravel infiltration systems and filters: Insights from a laboratory study[J]. Water Research, 2007, 41:1433-1440 -
