真空膜蒸馏和膜吸收及其集成工艺处理高氨氮废水

,  ,  ,

downloadPDF

上一篇

下一篇

段明星, 王建兵, 王军, 纪仲光. 真空膜蒸馏和膜吸收及其集成工艺处理高氨氮废水[J]. 环境工程学报, 2015, 9(2): 659-664. doi: 10.12030/j.cjee.20150225
引用本文: 段明星, 王建兵, 王军, 纪仲光. 真空膜蒸馏和膜吸收及其集成工艺处理高氨氮废水[J]. 环境工程学报, 2015, 9(2): 659-664. doi: 10.12030/j.cjee.20150225
shu
Duan Mingxing, Wang Jianbing, Wang Jun, Ji Zhongguang. Vacuum membrane distillation and membrane absorption and integrated process for ammonia removal from wastewater[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 659-664. doi: 10.12030/j.cjee.20150225
Citation: Duan Mingxing, Wang Jianbing, Wang Jun, Ji Zhongguang. Vacuum membrane distillation and membrane absorption and integrated process for ammonia removal from wastewater[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 659-664. doi: 10.12030/j.cjee.20150225
shu

真空膜蒸馏和膜吸收及其集成工艺处理高氨氮废水

  • 1.

    中国矿业大学(北京)化学与环境工程学院, 北京 100083

  • 2.

    中国科学院生态环境研究中心环境水质学国家重点实验室, 北京 100085

  • 基金项目:

    国家自然科学基金资助项目(51378491)

    国家"水体污染控制与治理"科技重大专项(2012ZX07202006-003-2)

  • 中图分类号: TQ028.8

Vacuum membrane distillation and membrane absorption and integrated process for ammonia removal from wastewater

  • 1.

    School of Chemical & Environmental Engineering, China University of Mining & Technology, Beijing 100083, China

  • 2.

    State Key Laboratory of Environmental Aquatic Chemistry, Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing 100085, China

  • Fund Project:

  • 摘要: 采用PP中空纤维膜组件,对VMD(真空膜蒸馏)和MA(膜吸收)脱氨过程进行了研究。考察了料液pH值(9.0~11.0)、料液进口温度(20~50℃)对脱氨效率的影响。研究结果表明,VMD和MA脱除率分别达85%和99%以上。料液pH和料液进口温度对VMD脱氨效果的影响较大,提高料液pH和进口温度可以明显提高VMD的脱氨效率;料液pH对MA的脱氨效率影响较为显著。对2种膜工艺进行了技术集成,利用该集成工艺可达到99.96%以上的氨去除率,出水可达标排放,并且可以有效防止硫酸铵的二次污染。
    Abstract: Two kinds of membrane technologies- vacuum membrane distillation (VMD) and membrane absorption (MA) were adopted for ammonia removal from wastewater with PP hollow fiber membrane modules. The influences of feed pH (9.0~11.0) and inlet temperature (20~50℃) on ammonia removal efficiency were investigated. The results show that ammonia removal efficiencies of VMD and MA can reach to 85% and 99%, respectively. Feed pH and inlet temperature have a significant influence on ammonia removal of VMD.The increases of feed pH and inlet temperature improve ammonia removal of VMD significantly. But for MA, only feed pH has an obvious impact on ammonia removal. In addition, VMD and MA were integrated for ammonia removal in this work. Ammonia removal efficiency reaches to 99.96% with this new membrane technology. The treated water reaches discharge standard and the secondary pollution of ammonium sulfate can be prevented efficiently.
  • 加载中
  • [1] 应德煌.氨氮废水治理方案的选择.福建化工,2003,(2):50-54 Ying D.H. Selection of treatment of Ammonia wastewater. Fujian Chemical, 2003, (2):50-54(in Chinese)
    [2] Cooney Emma L., Booker Nicholas A., Shallcross David C. Ammonia removal from waste water using natural Australian zeolite. I. Characterization of the zeolite. Separation Science and Technology, 1999, 34 (12):2307-2327
    [3] Zhu G.B., Peng Y.Z., Zhai L.M., et al. Performance and optimization of biological nitrogen removal process enhanced by anoxic/oxic step feeding. Biochemical Engineering Journal, 2009, 43(3):280-287
    [4] Carrera J., Baeca J.A., Vicent T., et al. Biological nitrogen removal of high-strength ammonium industrial wastewater with two-sludge system. Water Research, 2003, 37(17): 4211-4221
    [5] 袁捷,杨宁,周艳军.吹脱法处理高浓度氨氮废水的研究.化学工业与工程技术,2009,30(4):55-57 Yuan J., Yang N., Zhou Y.J. Research on striping treatment of high concentrated ammonia nitrogen wastewater. Journal of Chemical Industry & Engineering,2009,30(4):55-57(in Chinese)
    [6] Jeffrey W.A. Charrois, Steve E.,et al. Breakpoint chlorination and free-chlorine contact time: Implications for drinking water N-nitrosodimethylamine concentrations. Water Research,2007,41(3): 674-682
    [7] Zhang T., Ding L.L., Ren H.Q., et al. Ammonium nitrogen removal from coking wastewater by chemical precipitation recycle technology. Water Research,2009, 43(20):5209-5215
    [8] Huang C.M., Lou J.C., Lin C.H. Removal of ammonia solutions used in catalytic wet oxidation processes. Chemosphere, 2003, 52(6):989-995
    [9] Mandowara A., Prashant K., Bhattacharya. Simulation studies of ammonia removal from water in a membrane contactor under liquid-liquid extraction mode. Journal of Environmental Management, 2011, 92(1):121-130
    [10] Mondor M., Masse L., Ippersiel D.,et al. Use of electrodialysis and reverse osmosis for the recovery and concentration of ammonia from swine manure. Bioresource Technology, 2008, 99(15):7363-7368
    [11] Walker M., Iyer K., Heaven S., et al. Ammonia removal in anaerobic digestion by biogas stripping: An evaluation of process alternatives using a first order rate model based on experimental fimmonia Chemical Engineering Journal, 2011, 178(24):138-145
    [12] Garrido J.M., Guerrero L., Mendez R., et al. Nitification ofwaste waters from fish-meal factories.Water SA, 1998, 24(3):245-249
    [13] 黄伟.減压膜蒸馏法处理石煤提钒废水研究.武汉:武汉理工大学硕士学位论文,2012 Huang W. Vacuum membrane distillation treatment of wastewater produced in vanadium extraction from stone coal.Wuhan:Master Dissertation of Wuhan University of Technology, 2012 (in Chinese)
    [14] 程鹏高,唐娜,王学魁.减压膜蒸馏浓缩盐水溶液的研究现状.化工进展,2007,27(7):1027-1031 Cheng P.G., Tang N., Wang X.K. Research on aqueous salt solution desalination by vacuum membrane distillation. Chemical Industry and Engineering Progress, 2007, 27 (7):1027-1031(in Chinese)
    [15] 时钧,袁权,高从堦.膜技术手册.北京:化学工业出版社,2001: 760-762
    [16] Mulder M.膜技术基本原理.北京:清华大学出版社,1996, 243-247
    [17] 齐麟,吕晓龙,贾悦.膜吸收从废水中脱氨的研究.水处理技术,2008,34(5):7-11 Qi L., Lü X.L., Jia Y. Study of membrane absorption process on separating ammonia from wastewater. Technology of Water Treatment, 2008,34(5):7-11(in Chinese)
  • 加载中
