建设用地土壤优先管理有毒有害物质研究
A Study on Soil Priority Management of Toxic and Hazardous Substances for Development Land
-
摘要: 筛选建设用地土壤的优先管理有毒有害物质，是开展土壤污染状况调查与风险评估、制定土壤质量标准和支撑土壤污染重点监管单位管理的依据。本文首先整合国内外多源数据进行土壤有毒有害物质筛选，然后通过化学排序并结合数理统计方法确立我国建设用地土壤优先管理的有毒有害物质名录。结果表明，通过国外与国内多源数据可以整合出886种候选土壤有毒有害物质，采用数据集合并的方法可筛选出123种应关注的土壤有毒有害物质。在此基础上，通过改进的化学排序系统，从人体毒性、暴露潜力、环境管理关注度和数据确定性4个层面，对土壤有毒有害物质进行参数化赋分与定量评价，并结合确定性得分结果，建立了含有99种物质的土壤优先管理有毒有害物质清单，其中苯并(a)芘的总得分最高，其次是镉和砷；2-氯萘和邻苯二甲酸二乙酯的总得分最低。最后，通过K均值聚类算法将99种土壤优先管理有毒有害物质划分为5个不同的优先等级，其中苯并(a)芘、镉、砷、汞、铅、镍、苯、六价铬和茚并(1,2,3-cd)芘等9种物质被划定为第一优先等级。最终，结合排放标准制定现状和分析测试方法具备情况，建议可将除茚并(1,2,3-cd)芘以外的第一优先等级物质纳入我国首批重点控制的土壤有毒有害物质名录。Abstract: Screening toxic and hazardous substances that need priority management in development land soils is the basis of contamination investigation, risk assessment, quality standard development of soils, and is also the basis of soil pollution management for supervision entities. In this study, the chemical sorting combined with a statistical method was performed on a multi-source dataset that integrating both domestic and foreign data in order to screen soil toxic and hazardous substances that need priority management. In the dataset, we selected 886 toxic and hazardous substances in candidate, and via the integrated analysis method, extracted a list of 123 substances from them that need particular attention for priority management. The parameterized scoring and quantitative evaluation of the 123 toxic and hazardous substances in concern were then carried out using an improved chemical ranking system in terms of human toxicity, exposure potential, environmental management concern, and data certainty. By combining the results of the data certainty score, we established a sequential list of 99 toxic and hazardous substances for priority management. Among which, B(a)P has the highest total score followed by cadmium and arsenic, while 2-chlorine naphthalene and diethyl phthalate had the lowest. Finally, the 99 substances were classified into five priority levels by K-means clustering algorithm. B(a)P, Cd, As, Hg, Pb, Ni, benzene, Cr(Ⅵ), and indeno(1,2,3-cd)pyrene were classified in the first-level priority. Considering the current status of emission standards and soil analytical methods in China, we propose the first-level substances, with the exception of indeno(1,2,3-cd)pyrene, to be included in the first catalog of toxic and hazardous substances under priority control for soil.
-
-
迭庆杞, 黄泽春, 杨玉飞, 等. 我国农药工业危险废物产生和污染特性研究[J]. 环境工程技术学报, 2021, 11(6): 1266-1272 Die Q Q, Huang Z C, Yang Y F, et al. Research on the generation and pollution characteristics of pesticide industrial hazardous wastes in China[J]. Journal of Environmental Engineering Technology, 2021, 11(6): 1266-1272(in Chinese)
姜林, 张文毓, 钟茂生, 等. 危险物质泄漏场地污染应急响应与清理制度及关键技术[J]. 环境科学研究, 2021, 34(10): 2438-2445 Jiang L, Zhang W Y, Zhong M S, et al. Emergency response and removal program and technologies to contaminated sites by hazardous substances releases[J]. Research of Environmental Sciences, 2021, 34(10): 2438-2445(in Chinese)
韦正峥, 向月皎, 郭云, 等. 国内外新污染物环境管理政策分析与建议[J]. 环境科学研究, 2022, 35(2): 443-451 Wei Z Z, Xiang Y J, Guo Y, et al. Analysis and suggestions of environmental management policies of new pollutants at home and abroad[J]. Research of Environmental Sciences, 2022, 35(2): 443-451(in Chinese)
王俭, 路冰, 李璇, 等. 环境风险评价研究进展[J]. 环境保护与循环经济, 2017, 37(12): 33-38 李东艳, Francois M, 任玉芬, 等. 重金属污染土壤萃取方法选择及参数优化[J]. 地学前缘, 2005, 12(S1): 189-192 Li D Y, Francois M, Ren Y F, et al. Selection of extraction procedures and optimization of parameters for the determination of forms of heavy metals in soils[J]. Earth Science Frontiers, 2005, 12(S1): 189-192(in Chinese)
Division of Toxicology and Human Health Sciences, Agency for Toxic Substances and Disease Registry (ATSDR). Support Document to the 2019 Substance Priority List (Candidates for Toxicological Profiles)[EB/OL].[2022-03-30]. http://www.atsdr.cdc.gov/spl/resources/ATSDR-2019-SPL-Support-Document-508/,2020-4 The Department for Environment, Food and Rural Affairs and the Environment Agency. CLRR 8 Potential contaminants for the assessment of land[R/OL].[2022-03-30]. http://www.environment-agency.gov.uk 窦小利. 日本《土壤污染对策法》及其对我国立法的启示[C]// 中国法学会环境资源法学研究会,国家环境保护总局, 全国人大环资委法案室, 兰州大学. 中国法学会环境资源法学研究会环境法治与建设和谐社会—2007年全国环境资源法学研讨会(年会)论文集(第三册). 兰州: 中国法学会环境资源法学研究会,国家环境保护总局, 全国人大环资委法案室, 兰州大学, 2007: 111-117 Jeong S W, An Y J. Construction of a chemical ranking system of soil pollution substances for screening of priority soil contaminants in Korea[J]. Environmental Monitoring and Assessment, 2012, 184(4): 2193-2204 张丽丽, 朱晓晶, 于洋, 等. 京津冀及周边地区优先控制有毒有害大气污染物名录研究[J]. 环境科学研究, 2021, 34(1): 194-201 Zhang L L, Zhu X J, Yu Y, et al. Priority control of hazardous air pollutants in Beijing-Tianjin-Hebei and its surrounding areas[J]. Research of Environmental Sciences, 2021, 34(1): 194-201(in Chinese)
徐晓琳, 李红莉, 高虹, 等. 我国水生生态系统优先控制有机污染物的研究现状[J]. 环境科学研究, 2003, 16(2): 27-30 Xu X L, Li H L, Gao H, et al. Research status of priority-control organic pollutants in aquatic ecosystem in China[J]. Research of Environmental Sciences, 2003, 16(2): 27-30(in Chinese)
葛峰, 徐坷坷, 云晶晶, 等. 我国土壤环境基准优先污染物的筛选及清单研究[J]. 中国环境科学, 2018, 38(11): 4228-4235 Ge F, Xu K K, Yun J J, et al. Studies on screening and list of priority pollutants in China's soil criteria research[J]. China Environmental Science, 2018, 38(11): 4228-4235(in Chinese)
生态环境部. 工矿用地土壤环境管理办法(试行)[EB/OL]. (2018-05-03)[2020-10-09]. https://www.mee.gov.cn/xxgk2018/xxgk/xxgk02/201805/t20180510_629535.html United States Environmental Protection Agency. Regional Screening Levels-Generic Tables[S/OL].[2022-03-30]. https://www.epa.gov/risk/regional-screening-levels-rsls-generic-tables Environment Agency. Updated technical background to the CLEA model (ScienceReport Final SC050021/SR3)[R]. Bristol: Environment Agency, United Kingdom, 2009 Japanese Ministry of the Environment. Environmental quality standards for soil pollution[EB/OL]. (1998-08-23)[2022-03-30]. http://www.env.go.jp/en/water/soil/sp.html.1991-08-23 Ministry of Housing, Spatial Planning and Environment. Ministerial circular on target and intervention values[R]. The Hague: Ministry of Housing, Spatial Planning and Environment, 2000 Carlon C. Derivation methods of soil screening values in Europe. A review and evaluation of national procedures towards harmonization[R]. Brussels: European Commission, Directorate General, Joint Research Centre, 2007: 1-320 Jensen J, Folker-Hansen P. Soil quality criteria for selected organic compounds[R]. Odense, Denmark: Danish Environmental Protection Agency, 1995: 1-156 Swiss Agency for the Environment, Forests and Landscape. Commentary on the ordinance of 1 July 1998 relating to impacts on the soil (OIS)[J]. Berne: Swiss Agency for the Environment, Forests and Landscape, 2001 Canadian Council of Ministers of Environment. A protocol for the derivation of environmental and human health soil quality guidelines[R]. Winnipeg: Canadian Council of Ministers of Environment, 2006 The Department of Environment and Conservation. Assessment levels for soil, sediment and water[R]. Western Australia: The Department of Environment and Conservation, Australia,2010: 1-41 Ferguson C. Assessing risks from contaminated sites: Policy and practice in 16 European countries[J]. Land Contamination & Reclamation, 1999, 7(2): 33-54 生态环境部, 国家卫生健康委员会. 有毒有害水污染物名录(第一批)[EB/OL]. (2019-07-24)[2020-10-10]. https://www.mee.gov.cn/xxgk2018/xxgk/xxgk01/201907/t20190729_712633.html 生态环境部. 有毒有害大气污染物名录(2018年)[EB/OL]. (2019-02-05)[2020-10-10]. http://www.gov.cn/xinwen/2019-02/05/content_5364004.htm 生态环境部, 国家发展和改革委员会, 公安部. 国家危险废物名录(2021年版)[EB/OL]. (2020-11-27)[2021-03-20].https://www.mee.gov.cn/xxgk2018/xxgk/xxgk02/202011/t20201127_810202.html 环境保护部, 工业和信息化部, 国家卫生和计划生育委员会. 优先管理化学品名录(第一批)[EB/OL]. (2017-12-28)[2020-10-15]. https://www.mee.gov.cn/gkml/hbb/bgg/201712/t20171229_428832.html 生态环境部, 工业和信息化部, 国家卫生健康委员会. 优先管理化学品名录(第二批)[EB/OL]. (2020-11-02)[2021-03-12]. https://www.mee.gov.cn/xxgk2018/xxgk/xxgk01/202011/t20201102_805937.html 生态环境部, 国家市场监督管理总局. 土壤环境质量建设用地土壤污染风险管控标准: GB 36600—2018[S]. 北京: 中国标准出版社, 2018 河北省市场监督管理局. 建设用地土壤污染风险筛选值: DB13/T 5216—2020[S]. 石家庄: 河北省市场监督管理局, 2020 江西省市场监督管理局, 江西省生态环境厅. 江西省建设用地土壤污染风险管控标准(试行): DB 36/1282—2020[S]. 南昌: 江西省市场监督管理局, 江西省生态环境厅, 2020 北京市质量技术监督局. 场地土壤环境风险评价筛选值: DB11/T 811—2011[S]. 北京: 北京市质量技术监督局, 2011 重庆市质量技术监督局. 重庆市场地土壤环境风险评估筛选值: DB50/T 723—2016[S]. 重庆: 重庆市质量技术监督局, 2016 湖南省环境保护厅, 湖南省质量技术监督局. 湖南省重金属污染场地土壤修复标准: DB43/T 1165—2016[S]. 长沙: 湖南省环境保护厅, 湖南省质量技术监督局, 2016 辽宁省质量技术监督局, 辽宁省生态环境厅. 辽环综函[2020]364号辽宁省污染场地风险评估筛选值[R]. 沈阳: 辽宁省质量技术监督局, 辽宁省生态环境厅, 2020 深圳市市场监督管理局. 深圳市土壤污染风险筛选值和管制值: DB4403/T 67—2020[S]. 深圳: 深圳市市场监督管理局, 2020 浙江省质量技术监督局. 污染场地风险评估技术导则: DB33/T 892—2013[S]. 杭州: 浙江省质量技术监督局, 2013 广东省质量技术监督局. 珠江三角洲土壤重金属风险评价筛选值: DB44/T 1415—2014[S]. 珠江: 广东省质量技术监督局, 2014 International Agency of Research on Cancer (IARC). List of Classifications[DB].[2022-03-30]. https://monographs.iarc.fr/list-of-classifications United States Environmental Protection Agency. Integrated Risk Information System (IRIS)[DB].[2022-03-30]. https://iris.epa.gov/AtoZ/?list_type=alpha United States Environmental Protection Agency. Regional Screening Levels Calculator (RSL Calculator)[S/OL].[2022-03-30]. https://epa-prgs.ornl.gov/cgi-bin/chemicals/csl_search United States Environmental Protection Agency. Hazardous Substances Data Bank (HSDB) (2019)[DB].[2022-03-30]. https://comptox.epa.gov/dashboard/chemical_lists/HSDB2019 European Union. Regulations No 1272/2008[R]. Brussels: European Union, 2008 Guo Q R, Wei D B, Wang F P, et al. A novel risk score-based prioritization method for pollutants in reclaimed water[J]. The Science of the Total Environment, 2021, 795: 148833 赵静, 孙海娟, 冯叙桥. 食品中重金属铅污染状况及其检测技术研究进展[J]. 食品与发酵工业, 2014, 40(9): 122-127 Zhao J, Sun H J, Feng X Q. Research progress on the pollution of heavy metals lead and its detection technology in food[J]. Food and Fermentation Industries, 2014, 40(9): 122-127(in Chinese)
European Union. Endocrine Disruptors Regulations and Lists in EU[EB/OL]. (2021-10-01)[2022-03-30]. https://www.chemsafetypro.com/Topics/EU/Endocrine_Disruptors_Regulations_and_Lists_in_EU.html United States Environmental Protection Agency. EPI suite, ACD/Labs[DB].[2022-03-30]. http://www.chemspider.com/ 辽宁省放射环境监理站. 常用放射性核素名称及半衰期表[R/OL].[2022-03-30]. http://www.doc88.com/p-8455678928217.html -
