柿粉树脂的制备及其吸附Cu2+和Pb2+的效应

,  ,  ,  ,

downloadPDF

上一篇

下一篇

谢枫, 樊睿怡, 张青林, 郭大勇, 罗正荣. 柿粉树脂的制备及其吸附Cu2+和Pb2+的效应[J]. 环境工程学报, 2015, 9(2): 711-718. doi: 10.12030/j.cjee.20150234
引用本文: 谢枫, 樊睿怡, 张青林, 郭大勇, 罗正荣. 柿粉树脂的制备及其吸附Cu2+和Pb2+的效应[J]. 环境工程学报, 2015, 9(2): 711-718. doi: 10.12030/j.cjee.20150234
shu
Xie Feng, Fan Ruiyi, Zhang Qinglin, Guo Dayong, Luo Zhengrong. Preparation of persimmon powder resin and its performance for adsorption of Cu2+ and Pb2+[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 711-718. doi: 10.12030/j.cjee.20150234
Citation: Xie Feng, Fan Ruiyi, Zhang Qinglin, Guo Dayong, Luo Zhengrong. Preparation of persimmon powder resin and its performance for adsorption of Cu2+ and Pb2+[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 711-718. doi: 10.12030/j.cjee.20150234
shu

柿粉树脂的制备及其吸附Cu2+和Pb2+的效应

  • 1.

    华中农业大学园艺植物生物学教育部重点实验室, 武汉 430070

  • 2.

    江西省农业科学院园艺研究所, 南昌 330200

  • 基金项目:

    公益性行业(农业)科研专项(201203047)

    中央高校基本科研业务费专项(2009PY024)

  • 中图分类号: X703.1;X131

Preparation of persimmon powder resin and its performance for adsorption of Cu2+ and Pb2+

  • 1.

    Key Laboratory of Horticultural Plant Biology, Huazhong Agricultural University, Wuhan 430070, China

  • 2.

    Institute of Horticultural Sciences, Jiangxi Academy of Agricultural Sciences, Nanchang 330200, China

  • Fund Project:

  • 摘要: 以柿粉为原料通过甲醛交联固化制备出柿粉树脂(PPR);利用傅里叶红外光谱(FT-IR)、Zeta电位、热变性温度、比表面积等对其进行表征,并探讨其吸附Cu2+和Pb2+的效应。结果表明,(1)PPR对Cu2+和Pb2+的吸附效果显著高于柿粉与活性炭;(2)pH值对吸附平衡影响较大,最佳pH值范围为5.0~6.0;(3)PPR对Cu2+和Pb2+的吸附在180 min内可达到吸附平衡,提高吸附温度可提高吸附速率,其吸附动力学数据可用拟二级速率方程良好拟合;(4)提高金属离子初始浓度可增加平衡吸附量,Freundlich和Langmuir方程可分别拟合PPR对Cu2+(R2 > 0.98)和Pb2+(R2 > 0.99)的吸附等温线;(5)PPR(2.0 g/L)可吸附混合重金属溶液中83.73% 的Cu2+和98.63% 的Pb2+;(6)PPR可循环使用5次以上;(7)PPR对Cu2+与Pb2+的吸附效应可能是静电吸附与配位反应共同作用的结果。该研究结果表明,PPR是一种有应用前景的处理含重金属废水的备选材料。
    Abstract: A new adsorption resin (persimmon powder resin, PPR) was developed by immobilizing persimmon powder with formaldehyde, and it was characterized by FT-IR spectra, Zeta potentials, thermal denaturation temperature and BET specific surface area. The adsorption properties to Cu2+ and Pb2+ were investigated. The adsorption capacity of Cu2+ and Pb2+ on PPR was much higher than persimmon power and activated carbon. The results indicated that the adsorption capacity of Cu2+ and Pb2+ depended on the solution pH, and the optimal pH range was 5.0~6.0. The adsorption of Cu2+ and Pb2+ was rapid which could reach adsorption equilibrium within 180 min, and the adsorption kinetics data were well fitted with the pseudo-second-order rate model. Higher temperature led to higher adsorption rate and higher concentration of solutions led to higher equilibrium adsorption capacity. The adsorption isotherms of Cu2+ on PPR could be well described by Freundlich equation (R2 > 0.98) while the adsorption isotherms of Pb2+ on PPR were well fitted with the Langmuir equation (R2 > 0.99). The resin exhibited high adsorption capacity towards Cu2+ and Pb2+ from coexisting metal ions solution, and the pollutant removal reached 83.73% and 98.63% when the adsorbent dose was 2.0 g/L, respectively. The regeneration and reusability tests result indicated the PPR was suitable for repeated use for more than five cycles. The adsorption mechanism of Cu2+ and Pb2+ on PPR might be the combination of electrostatic attraction and coordination reaction. This suggested that the resin can be used as an active biosorbent for the removal of heavy metal ions from aqueous environment.
  • 加载中
  • [1] 夏良树,谭凯旋,王晓,等.铀在榕树叶上的吸附行为及其机理分析.原子能科学技术, 2010,44,(3):278-284
    [2] Xia Liangshu, Tan Kaixuan, Wang Xiao. Adsorption behavior of uranium and mechanism analysis on banyan leaves. Atomic Energy Science and Technology, 2010,44(3):278-284(in Chinese)
    [3] 黄国林,陈中胜,梁喜珍. 磁性交联壳聚糖对水溶液中铀(Ⅵ)离子的吸附行为. 化工学报, 2012,63(3):834-840
    [4] Huang Guolin, Chen Zhongsheng, Liang Xizhen. Adsorption behavior of U(VI) ions from aqueous solution on cross-linked magnetic chitosan beads. Journal of Chemical Industry and Engineering,2012, 63(3): 834-840 (in Chinese)
    [5] 张婧. 凹凸棒土处理含铅废水与高氟水的吸附热力学及机理研究. 北京:北京大学硕士学位论文, 2008
    [6] Zhang Jing. Thermodynamics and mechanism study on removal of lead and fluoride ions from aqueous solution by adsorption onto attapulgite.Beijing:Master Dissertation of Peking University, 2008(in Chinese)
    [7] 高兰玲,夏德强,冷宝林. 凹凸棒的改性方法及在废水处理中的应用进展. 化学工程与装备,2011,(9):225-227
    [8] Gao Lanling, Xia Deqiang, Leng Baolin. Progress on the modification of attapulgite and its application in wastewater treatment. Chemical Engineering & Equipment, 2011,(9):225-227(in Chinese)
    [9] 蒋海燕. 不溶性腐殖酸及腐殖酸修饰的凹凸棒处理废水中铀(VI)的试验研究.衡阳:南华大学硕士学位论文, 2013
    [10] Jiang Haiyan. Study on removal of Uranium(VI) from aqueous solution by adsorption onto insoluble humic acid and humic acid modified attapulgite.Hengyang:Master Dissertation of University of South China, 2013(in Chinese)
    [11] Yijiang Zhao, Yan Chen, Meisheng Li. Adsorption of Hg2+ from aqueous solution onto polyacrylamide/attapulgite. Journal of Hazardous Materials, 2009,171(1-3): 640-646
    [12] Katja Schmeide, Susanne Sachs, Marianne Bubner. Interaction of uranium(VI) with various modified and unmodified natural and synthetic humic substances studied by EXAFS and FTIR spectroscopy. Inorganica Chimica Acta, 2003, 351(6): 133-140
    [13] Sachs S., Bernhard G.. Sorption of U(VI) onto an artificial humic substance-kaolinite-associate. Chemosphere,2008,72(10):1441-1447
    [14] Niu Zhiwei, Fan Qiaohui, Wang Wenhua. Effect of pH, ionic strength and humic acid on the sorption of uranium(VI) to attapulgite. Applied Radiation and Isotopes, 2009, 67(9): 1582-1590
    [15] Anirudhan T.S., Bringle C.D. Removal of uranium (VI) from aqueous solutions and nuclear industry effluents using humic acid-immobilized zirconium-pillared clay. Journal of Environmental Radioactivity, 2010, 101(3): 267-276
    [16] Mahmoud Wazne, Georgep Korfiatis, Xiaoguang Meng. Carbonate effects on hexavalent uranium adsorption by iron oxyhydroxide. Environmental Science & Technology, 2003, 37(16):3619-3624
    [17] 彭国文,丁德馨,胡南. 化学修饰啤酒酵母菌对铀的吸附特性. 化工学报, 2011, 62(11):3201-3206
    [18] Peng Guowen, Ding Dexin, Hu Nan. Adsorption characteristics of uranium by Saccharomyces cerevisiae by chemical modification. Journal of Chemical Industry and Engineering, 2011, 62(11):3201-3206(in Chinese)
    [19] Febrianto J., Natasia Kosasih A., Sunarso J., et al. Equilibrium and kinetic studies in adsorption of heavy metals using biosorbent: A summary of recent studies. Journal of Hazardous Materials,2009,162(2-3):616-645
    [20] 张伟,杨柳,蒋海燕,等. 污泥活性炭的表征及其对Cr(VI)的吸附特性. 环境工程学报,2014,8(4):1439-1446
    [21] Zhang Wei,Yang Liu,Jiang Haiyan. Characterization of sludge-based activated carbon and its adsorption properties on Cr(VI). Chinese Journal of Environmental Engineering, 2014,8(4):1439-1446(in Chinese)
    [22] 刘娟,陈迪云, 张静,等. 铀在凹凸棒上的吸附特性与机制研究. 环境科学,2012,33(8):2889-2894
    [23] Liu Juan,Chen Diyun,Zhang Jing. Adsorption characteristics and mechanism of uranium on attapulgite. Environmental Science, 2012,33(8):2889-2894(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2170
  • HTML全文浏览数:  1491
  • PDF下载数:  913
  • 施引文献:  0
出版历程
  • 收稿日期:  2014-02-21
  • 刊出日期:  2015-02-07
谢枫, 樊睿怡, 张青林, 郭大勇, 罗正荣. 柿粉树脂的制备及其吸附Cu2+和Pb2+的效应[J]. 环境工程学报, 2015, 9(2): 711-718. doi: 10.12030/j.cjee.20150234
引用本文: 谢枫, 樊睿怡, 张青林, 郭大勇, 罗正荣. 柿粉树脂的制备及其吸附Cu2+和Pb2+的效应[J]. 环境工程学报, 2015, 9(2): 711-718. doi: 10.12030/j.cjee.20150234
shu
Xie Feng, Fan Ruiyi, Zhang Qinglin, Guo Dayong, Luo Zhengrong. Preparation of persimmon powder resin and its performance for adsorption of Cu2+ and Pb2+[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 711-718. doi: 10.12030/j.cjee.20150234
Citation: Xie Feng, Fan Ruiyi, Zhang Qinglin, Guo Dayong, Luo Zhengrong. Preparation of persimmon powder resin and its performance for adsorption of Cu2+ and Pb2+[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 711-718. doi: 10.12030/j.cjee.20150234
shu

柿粉树脂的制备及其吸附Cu2+和Pb2+的效应

  • 1.  华中农业大学园艺植物生物学教育部重点实验室, 武汉 430070
  • 2.  江西省农业科学院园艺研究所, 南昌 330200
  • 收稿日期:  2014-02-21
基金项目:

公益性行业(农业)科研专项(201203047)

中央高校基本科研业务费专项(2009PY024)

摘要: 以柿粉为原料通过甲醛交联固化制备出柿粉树脂(PPR);利用傅里叶红外光谱(FT-IR)、Zeta电位、热变性温度、比表面积等对其进行表征,并探讨其吸附Cu2+和Pb2+的效应。结果表明,(1)PPR对Cu2+和Pb2+的吸附效果显著高于柿粉与活性炭;(2)pH值对吸附平衡影响较大,最佳pH值范围为5.0~6.0;(3)PPR对Cu2+和Pb2+的吸附在180 min内可达到吸附平衡,提高吸附温度可提高吸附速率,其吸附动力学数据可用拟二级速率方程良好拟合;(4)提高金属离子初始浓度可增加平衡吸附量,Freundlich和Langmuir方程可分别拟合PPR对Cu2+(R2 > 0.98)和Pb2+(R2 > 0.99)的吸附等温线;(5)PPR(2.0 g/L)可吸附混合重金属溶液中83.73% 的Cu2+和98.63% 的Pb2+;(6)PPR可循环使用5次以上;(7)PPR对Cu2+与Pb2+的吸附效应可能是静电吸附与配位反应共同作用的结果。该研究结果表明,PPR是一种有应用前景的处理含重金属废水的备选材料。
